Box of 100 Simpson Strong-Tie A35E Universal Framing Anchor Pre-Galvanised

Load image into Gallery viewer, Box of 100 Simpson Strong-Tie A35E Universal Framing Anchor Pre-Galvanised

Box of 100 Simpson Strong-Tie A35E Universal Framing Anchor Pre-Galvanised

Name: Box of 100 Simpson Strong-Tie A35E Universal Framing Anchor Pre-Galvanised
Brand: Simpson Strong-Tie
Price: 58.99 GBP
Availability: InStock

Simpson Strong-Tie

£58.99

Sale Sold out

Tax included. Shipping calculated at checkout.

Quantity must be 1 or more

A35E

Framing Anchors

The A35E anchor’s exclusive bending slot allows instant, accurate bending on site for all two and three-way connections.
• Balanced, completely reversible design allows the A35E to be used to secure a wide variety of connections.

Material

Pre-galvanised mild steel.

Benefits

Speed prong holds framing anchor in position to allow easier nailing,

Exclusive bending slots allow instant, accurate bending on site for all two and three-way ties.

Balanced, completely reversible design allows the A35 to be used for a wide variety of connections.

Applications

Suitable On

Wood to wood applications.

Product Dimensions

product.image_with_dim.alt - A35E - Framing Anchors

REFERENCES	PRODUCT DIMENSIONS [MM]				HOLES
	A	B	C	T	FLANGE A	FLANGE B
	A	B	C	T	Ø3,8	Ø3,8
A35E	33	33	114	1.2	6	6

Connection Type 2

REFERENCES	FASTENERS		INSTALLATION	CHARACTERISTIC CAPACITIES – TIMBER C24⁽³⁾ [KN]	SAFE WORKING LOADS – TIMBER C16 [KN]
	FLANGE A	FLANGE B		R_2,K	LONG TERM						MEDIUM TERM
	N3.75×30	N3.75×30		R_2,K	R_1,SWL	R_2,SWL	R_3,SWL	R_4,SWL	R_5,SWL	R_6,SWL	R_1,SWL	R_2,SWL	R_3,SWL	R_4,SWL	R_5,SWL	R_6,SWL
A35E (Install 2)	6	6	2	–	1.3	1.3	–	1.5	–	–	1.3	1.3	–	1.7	–	–

Connection Type 3

REFERENCES	FASTENERS		INSTALLATION	CHARACTERISTIC CAPACITIES – TIMBER C24⁽³⁾ [KN]	SAFE WORKING LOADS – TIMBER C16 [KN]
	FLANGE A	FLANGE B		R_2,K	LONG TERM						MEDIUM TERM
	N3.75×30	N3.75×30		R_2,K	R_1,SWL	R_2,SWL	R_3,SWL	R_4,SWL	R_5,SWL	R_6,SWL	R_1,SWL	R_2,SWL	R_3,SWL	R_4,SWL	R_5,SWL	R_6,SWL
A35E (Install 3)	6	3	3	5.3	–	1	–	–	0.6	1	–	1.1	–	–	0.7	1.1

(3) Based upon 2 No brackets installed diagonally opposite to each other

Connection Type 4

REFERENCES	FASTENERS		INSTALLATION	CHARACTERISTIC CAPACITIES – TIMBER C24⁽³⁾ [KN]	SAFE WORKING LOADS – TIMBER C16 [KN]
	FLANGE A	FLANGE B		R_2,K	LONG TERM						MEDIUM TERM
	N3.75×30	N3.75×30		R_2,K	R_1,SWL	R_2,SWL	R_3,SWL	R_4,SWL	R_5,SWL	R_6,SWL	R_1,SWL	R_2,SWL	R_3,SWL	R_4,SWL	R_5,SWL	R_6,SWL
A35E (Install 4)	6	6	4	5.3	–	1	1	0.6	–	–	–	1.1	1.1	0.7	–	–
